索具通用
| 规格参数 | 参数值 |
|---|---|
| IMPA编码 | 230152 |
| 产品单位 | PCE |
| 产品规格 | A drop forged, carbon steel shackle with an eye bolt which has a metric coarse thread on one end. Please specify Ungalvanized (Black) or Galvanized shackle is required. Galvanized. Size: Body dia: 8mm, Opening: 14mm, Thread Bolt & Nut: M10, Clear Length: 27mm, Pin dia: 10mm, S.W.L: 0.35ton. |
| 中文汉化 | 230152 直眼螺栓卸扣 镀锌 JIS-SC型 8毫米 安全工作负荷0.35吨 -----描述-----：一件采用锻打工艺制造的碳钢卸扣，配备一只带有公制粗牙螺纹端的吊环螺栓。订购时请明确说明是否需要镀锌或未镀锌（黑件）卸扣。 |
| IMPA版本 | 8th Edition |
以上内容为AI翻译，请正确甄别-The above content is translated by AI and the images are sourced from the internet. Please discern correctly.
